| Equipment Parameters | |
| Power source | 200V/50HZ |
| Mini permissible stirring volume | 200ml |
| Mini permissible Emulsifying volume | 600ml |
| Maxi permissible Emulsifying volume | 1000ml |
| Maxi working temperature | 120℃ |
| Can reach vacuum | -0.097MPa |
| Maximum treatment viscosity | 100,000cP |
| Stirring motor power | 150W |
| Stirring speed range | 0-200rpm |
| Stirring speed display | Digital display |
| Stirring paddle configuration | Anchor Helical Ribbon Wall scraping mixing paddle |
| Scraper material | PTFE |
| Homogeneous disperse motor power | 1300W |
| Homogeneous disperse speed range | 4000-26000rpm (optional 10000-30000rpm) |
| Homogeneous disperse speed display | LCD display |
| Homogeneous disperse timer | Included |
| Homogeneous working head configuration | 25DG |
| Reaction cover opening | Homogeneous machine hole + material bucket hole + temperature measuring hole + vacuum hole + 3 pcs functional hole |
| Discharge method | Bottom discharge and flip pour discharge |
| Lift support | 350 |
| The contact main material with the material | SIC, SS316L, borosilicate glass, FKM, and PTFE |
| Vacuum hole diameter | 10 |
| Glass Reaction jacket inlet / outlet diameter | 12 |
| Allowable ambient temperature | 5-40℃ |
| Allowable relative humidity | 80% |
| Overall dimension | 400×600×1200 |
| Standard weight | 35KG |
| Packing | wooden case |
Supported by a professional design center and national light industry research institutes, our technical core is led by senior engineers and experts. As a dedicated manufacturer of diverse cosmetic machinery and equipment, we have established a strong presence in the daily chemical machinery industry.
Our products serve industries including cosmetics, medicine, food, chemical, and electronics, catering to numerous internationally recognized enterprises worldwide.
YT-10P-5M Lipstick Freeing Tunnel
SME-65L Lipstick Machine
Lipstick Filling Machine
We offer a comprehensive range of production lines:
Lifting stroke: 300mm | Voltage: 220V | Power: 60W | High precision trapezoidal screw | Aluminum alloy material.
Large torque reducer motor | Power: 150W | Speed: 0-200rpm | Digital display | Anchor type ribbon impeller with PTFE wall scraping | Material: SS316L | SKF Bearings.
Brushless motor | Power: 1300W | Speed: 8000-30000rpm | Stepless speed control | SS316L Working head | SKF Bearings.
SS316L Cover | FKM Seal ring | 1L Glass reactor with jacket | Vacuum requirement: -0.09Mpa | Digital thermometer | Sanitary quick fitting joints.
Aluminum alloy base (white spray finish) | Integrated panel operation | Shock-proof feet | Functions: Start, Shutdown, Rise, Fall, Stirring control.
Exhibition Center & Professional Engineering
With years of experience in domestic and international installation, we have successfully managed hundreds of large-scale projects. We provide top-ranking project installation and management expertise. Our after-sales personnel are systemically trained in equipment maintenance and practical use, ensuring dedicated service for machinery, raw materials, and technical consultation.
Yes, we are a factory with over 20 years of manufacturing experience specializing in cosmetic and chemical machinery.
The warranty is one year. We also offer lifetime after-sales service and technical support even after the warranty period expires.
Our QC team tests machine performance and speed before shipment. We also provide testing procedure videos for customers who cannot visit in person.
Our machines feature a "fool-style" design for easy operation. We provide instruction videos and can send engineers for on-site training if needed.
Yes, OEM is acceptable. Most of our machines are custom-designed to meet specific customer requirements or production situations.
Customers are warmly welcome to visit our factory to observe the machines in operation and verify the quality firsthand.
